FS-250 PROGRAMMING MANUAL
4
Interface for the Technician Level
When the Technician Level is accessed using the password, the LCD display and
the keypad are used to program the panel, and to view the programming if desired.
The display acts as a menu and the keypad allows the user to navigate through the
menu of functions and change or print the programming. The following figure
describes the navigation used in this context:
A-esc: will backup to previous screen
B-fn1: will perform function 1
C-fn2: will perform function 2
D-Nxt: will step to the next screen
Each menu item is associated with "A", "B", "C", or "D" buttons on the keypad.
Pressing one of these keys will cause the panel to go to the function associated with
the button.
For example
A-Esc, will backup to previous screen
B-+20 Jumps ahead 20 devices
C-mor shows further options in list
D-+1, Jumps ahead 1
Aesc
Bfn1
Cfn2
Dnxt
ZNxxx P Aesc
ZoneType:PRESIG B+20
Timer:___ Sec Cmor
To Zone #:___ D +1
To Next Page
