Siemens GCP5000 - Table 8-3 Five Track Case, A80905 External Wiring Connectors

DETAILED CASE AND MODULE DESCRIPTION
_________________________________________________________________________________________________________
8-8
SIG-00-22-02 JUNE 2022 (Revised September 2022)
Version: B.1
Table 8-3 Five Track Case, A80905 External Wiring Connectors
REF. NO. CONNECTOR DESCRIPTION CONNECTOR
DESIGNATION
SIEMENS PART
NUMBER
1 4-pin cage clamp, female LONTALK
®
PROTOCOL Z715-09099-0000
2
Keyed 10-pin cage clamp,
female
Upper TRACK-1 Z715-02101-0001
3 Upper TRACK-2 Z715-02101-0002
4 Upper TRACK-3 Z715-02101-0003
5 Upper TRACK-4 Z715-02101-0004
6 Upper TRACK-5 Z715-02101-0005
7 6-pin screw terminal, male SSCC-1 power and lamp Z715-02118-0001
8
Keyed 4-pin cage clamp,
female
Upper SSCC-1 Z715-02106-0001
9 6-pin screw terminal, male SSCC-2 power and lamp Z715-02118-0002
10
Keyed 4-pin cage clamp,
female
Upper SSCC-2 Z715-02106-0002
11 10-pin cage clamp, female CPU Z715-02101-0007
12
Keyed 10-pin cage clamp,
female
lower TRACK-1 Z715-02101-0008
13 lower TRACK-2 Z715-02101-0009
14 lower TRACK-3 Z715-02101-0010
15 lower TRACK-4 Z715-02101-0011
16 lower TRACK-5 Z715-02101-0012
17 Lower SSCC-1 Z715-02101-0014
18 Lower SSCC-2 Z715-02101-0015
