4.7 RAST5 connector
Insertion force / contact
′
4 N
Withdrawal force / contact
″
1 N
Tightening torque / screw 0.5 Nm in accordance with DIN EN
60335-1
Contacting with flat pin connector 6.3 x 0.8 mm in accordance with DIN EN
46244
Male multipoint connector to RAST5
standard
Connection cross-sections conductor screw connection
∂
Stranded conductor
Cross-section max. 2.5 mm²
∂
Stranded conductor with ferrule
Cross-section max. 2.5 mm²
∂
Stripping length
Approx. 8 mm
4.8 RAST3.5 connector
Connection cross-sections conductor screw connection
∂
Stranded conductor fine-wired
(flexible)
Cross-section
Min. 0.14 mm²
Max. 1.5 mm²
∂
Stranded conductor fine-wired
(flexible) with ferrule
Cross-section
Min. 0.25 mm²
Max. 1 mm²
∂
Stripping length
Approx. 7 mm
∂
Tightening torque / screw
0.25 Nm
4.9 Signal cable AGV50
4.9.1 AZL2 ↑ BCI
Signal cable Color white
Unshielded
Conductor 4 x 0.141 mm²
With jack RJ11
Cable length
- AGV50.100 1 m
Location Under the burner hood (arrangements for
SKII EN 60730-1 additionally required)
4.10 Dummy plug for RJ11
Dummy plug For 6 pin modular plug (RJ11)
Supplier Recommendation:
Molex
Order no.: 085 999 3256
Mechanical data
Mechanical data
