1 CX75, M75 board layout
Jigs, Tools and Working materials for all described repairs:
- hot air blower
- soldering gun
- tweezers
- flux
- solder
Connector
MMC
Joystick
Connector
Display
Connector
Board to
Board
IO Jack
Slim
Connector
Antenna
Connector
Battery
Connector
Camera
Resister
Filter
Connector
SIM Card
Reade
r
IRDA
