Page 2 Milltronics MillPulse 600 – INSTRUCTION MANUAL 7ML19985DG02
Milltronics Millpulse 600
Milltronics Millpulse 600 is a heavy-duty 2-wire motion sensor that provides a solid state
switch output to a PLC
1
. It is used primarily for monitoring the speed of rotating,
reciprocating, or conveying equipment.
Milltronics Millpulse 600 has a circuit card and magnet assembly potted in the probe
body and comes complete with mounting flange and locknut. Milltronics Millpulse 600 is
connected in series with the PLC input (or other load) and acts as a switch, opening and
closing as the ferrous targets of the machinery being monitored pass in front of the probe.
1.
Milltronics Millpulse 600 is designed to work with Programmable Logic Control-
lers (PLC) with input characteristics compatible with the electrical portion of the
CENELEC 50040/36/37/38 standards for two wire proximity sensors.
