Siemens MindConnect IoT2040 Getting Started

Appendix
Getting Connected to MindSphere
80 Getting Started, 05/2018
Datatypes Conversion
The following table shows the Datatype Conversion:
IEC61131 elementary datatypes OPC UA built-in datatypes Required IOT Datapoint Type
BOOL Boolean boolean
SINT SByte int
USINT Byte int
INT Int16 int
UINT UInt16 int
DINT Int32 int
UDINT UInt32 int
LINT Int64 long
ULINT UInt64 long
BYTE Byte int
WORD UInt16 int
DWORD UInt32 int
LWORD UInt64 long
REAL Float double
LREAL Double double
STRING String string
CHAR Byte int
WSTRING String string
WCHAR UInt16 int
DT
DATE_AND_TIME
DateTime n/a
DATE DateTime n/a
TOD
TIME_OF_DAY
DateTime n/a
TIME Double double
Note
“NodeID“ is not a valid part of the OPC string anymore.
