Appendix
A.2 Technical specifications of MindConnect Nano
Getting Connected to MindSphere
82 Getting Started, 05/2018
EMC
Interference immunity on signal
cables >30m
• ±2 kV acc. to IEC 61000-4-5, surge, length > 30 m;
Interference immunity on signal
cables < 30m
• ±1 kV acc. to IEC 61000-4-4; burst; length < 3 m;
• ±2 kV acc. to IEC 61000-4-4; burst; length > 3 m;
Interference immunity against voltage surge
asymmetric interference ±2 kV acc. to IEC 61000-4-5, surge asymmetric
symmetric interference ±1 kV acc. to IEC 61000-4-5, surge symmetric
Interference immunity against high-frequency electromagnetic fields
Interference immunity against high
frequency radiation
• 10 V/m for 80 - 1000 MHz and 1.4 - 2 GHz, 80% AM acc. to IEC 61000-4-3;
• 3 V/m for 2 - 2.7 GHz, 80% AM acc. to IEC 61000-4-3;
• 10 V/m for 10 kHz - 80 MHz, 80% AM acc. to IEC 61000-4-6
Interference immunity to magnetic fields
Interference immunity to magnetic
fields at 50 Hz
100 A/m; to IEC 61000-4-8
Emission of conducted and non-conducted interference
Interference emission via line/AC
current cables
EN 61000-6-3, EN 61000-6-4, CISPR 22 Class B, FCC Class A
Degree and class of protection
IP (at the front) IP20
IP (rear) IP40
Standards, approvals, certificates
CE mark Yes
UL approval Yes
UL 508 Yes
cULus Yes
RCM (formerly C-TICK) Yes
KC approval Yes
EMC CE, EN 61000-6-4:2007, EN 61000-6-2:2005
EN 61000-6-2 Yes
Dust protection Protection against foreign bodies > 1 mm
FCC Yes
Marine approval
Germanischer Lloyd (GL) Yes
American Bureau of Shipping
(ABS)
Yes
Bureau Veritas (BV) Yes
