MJ-5 Communications Module
11
IP-
192:168:001:200
Displays current IP address
192.168.1.200 or xxx.xxx.xxx.xxx
NM-
255:255:255:000
Displays current Network Mask
255.255.255.0 or
xxx.xxx.xxx.xxx
GW-
000:000:000:000
Displays current Gateway
192.168.1.1 or xxx.xxx.xxx.xxx
TCP port
DNP Communication Port Number
20,000 or NN,NNN (not advisable to
change)
DNP Version
Displays the DNP Software version in use
XXXX
SL
IP Address for future network based firmware upgrades
ALTERNATE USE: IP address for slave 1 in Master Slave Configuration
XXX.XXX.XXX.XXX
SL2
IP Address for future network based firmware upgrades
ALTERNATE USE: IP address for slave 2 in Master Slave Configuration
XXX.XXX.XXXXXX
VCA mode
Enables/Disables Heartbeat feature
ON or OFF
AutoInhbTout
Controls time of Heartbeat
NNN (range 000-255)
5.5.1 Communications Menu Item Descriptions
Data Stat, DatPortBaud, Data Parity, and DataPortAddr
These menu items apply only to the Data Port located on the front of the MJ-5 Control Panel, and do not require
modification.
Reg Id (Regulator Identification)
This item allows you to uniquely identify each regulator in the system. The Regulator Id is accessible as a data item
via the communications module for most of the protocol selections.
Protocol
This item defines the protocol selection for the MJ-5 Communications Module. The selections are listed in Table
7-4.
2200NOA is a variation of the 2200 protocol with the address field suppressed. It is provided for testing the MJ-5
Communications Module with the MJXplorer software. The SPECIAL item allows a new protocol handler to be
included in the Communications Module code without forcing a modification to the Main Processor code (for the
protocol selection front panel screen).
Comm Baud
This menu item defines the data rate for the MJ-5 Communications Module. The standard asynchronous
communications data rates are available for selection. For proper communications, the Comm Baud setting must
match the baud setting of the other communicating device(s) in the network.
Comm Parity
This configuration item defines the parity selection for the communications module. For proper communications, the
Comm Parity setting must match the parity setting of the other communicating device(s) in the system.
This parity selection will override any default or inherent parity defined in the selected protocol. [For example, the
2200 protocol specification document defines the parity as even. The Comm Parity configuration item allows even
parity to be selected, but it also permits the system designer/installer to use an alternate parity selection if desired.]
Comm Address
