Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 | Toll Free: 1 • 866 • 396 • 2356 | www.dynafl o.com
P-PS2Q0619A
Table 1
Linear Actuator Mounting Parts List
Key Description Quantity
1 Bracket, Yoke - Sliding Stem 1
2 Mounting Bracket - Connecting Block 1
3 Adjusting Bracket - Feedback Loop 1
4 Feedback Arm Assembly 1
5 Feedback Loop 1
6 Washer - Feedback Loop 1
7 Hex Nut 4
8 Hex Cap Screw, Adjusting Bracket - Mounting 2
9 Lock-washer 4
10 Hex Cap Screw, Mounting Bracket - Positioner 2
11 Lock-washer, Mounting Bracket - Yoke (Not Shown) 2
12 Hex Cap Screw, Mounting Bracket - Positioner 4
13 Lock-washer, Mounting Bracket - Positioner 4
14 Airset Mounting Screw (Not Shown) 2
15
Hex Cap Screw - Connecting Block
(Not Included - Use Existing Cap Screws)
2
16 Airset Regulator (Not Shown) 1
17
Spacer, Mounting Bracket - Yoke
(Not Shown - Sizes 1046, 1069, & 2069 Only)
2
For Mounting Instructions refer to Pages 2, 7, & 11.
OLD LINEAR MOUNTING INSTRUCTIONS
5
To Next Page
