Installation
Wiring
1
11 |
22
Siemens
A6V11478123_en_a
Building Technologies
2019-02-01
1.4.3.2 Analog outputs
Analog outputs with voltage signal
Use Connecting devices that are controlled with a 0...10 V signal
Terminal AO1, AO2
Diagram
M
+
-
M
A
O1
A
O2
+
-
