Installation
Quick release fasteners and detached cover
1
6
| 22
Siemens
Building Technologies
1.2 Quick release fasteners and detached cover
● Open the housing with the quick release fasteners
● The cover can easily be detached completely
1
1
2
90°
2
2
1
