Siemens RDG100, RDG100T, RDG110, RDG140, RDG160 Basic Documentation CE1P3182en
Building Technologies Functions 28 May 2009
Parameter
Name Factory setting Range
RDG400
Dia
nostics & test
d01 Application type Diagnostics 0:= --- (No application)
1:= Single-duct
2:= Single-duct with el. heater
3:= Single-duct with radiator
4:= Single-duct with h/c coil
d02 X1 status Diagnostics 0 = Not activated (for DI)
1 = activated (DI)
0…49 °C = cur. temp. value (for AI)
00 = HC input short
100 = HC input open
d03 X2 status Diagnostics 0 = Not activated (for DI)
1 = activated (DI)
0…49 °C = cur. temp. value (for AI)
00 = HC input short
100 = HC input open
d04 D1 status Diagnostics 0 = Not activated (for DI)
1 = activated (DI)
00 = HC input short
100 = HC input open
d05 Test mode for checking the Y1/Y2
actuator direction
(press left button to escape)
--- “---“ = no signal on outputs Y1 and Y2
OPE = output Y1 forced open
CLO = output Y2 forced closing
