# Symbol Description # Symbol Description
1
Heating mode 10
Confirmation of parameters
2
Electrical heater active
11
Degrees Celsius
Degrees Fahrenheit
3
Cooling mode
12 Digits for room temperature and setpoint
4
Comfort mode
13
Button lock active
5
Energy Saving mode 14
Condensation in room (dewpoint sensor active)
6
Protection 15
Fault
7
Escape 16
Temporary timer function (visible when
operating mode is temporarily extended
presence or absence)
8
Digits for room temperature, setpoint,
etc.
17
Indicates that room temperature is displayed
5.3 Disposal
The device is classified as waste electronic equipment in terms of the European
Directive 2002/96/EC (WEEE) and should not be disposed of as unsorted muni-
cipal waste.
The relevant national legal rules are to be adhered to.
Regarding disposal, use the systems setup for collecting electronic waste.
Observe all local and applicable laws.
LCD display
