Siemens RUGGEDCOM RS8000T User Manual

Installing the Device
2.1.2Mounting the Device to a Rack
Removing the Device
To remove the device from a DIN rail, do the following:
1. Insert a flathead screwdriver into the slot of the sliding release and move it
down.
1
3
2
1
2
1
1
DIN Rail
2
DIN Rail Adapter
Figure2.2 Removing the Device from a DIN Rail
2. Swing the bottom of the device away from the DIN rail.
3. Lift the device off the DIN rail.
2.1.2 Mounting the Device to a Rack
To secure the device to a standard 48 cm (19 in) rack, do the following:
1. Remove the four screws from the side of the device.
RUGGEDCOM RS8000T
Installation Manual, 01/2021, C79000-G8976-1023-05
9
