Technical Specifications
5
This chapter provides important technical specifications related to the device.
5.1 Power Supply Specifications
Input Range
Power
Supply Type
Minimum Maximum
Internal Fuse
Rating
a b
Maximum Power
Consumption
c
12-24 VDC 10 VDC 36 VDC 6.3 A(F)
24 VDC 18 VDC 36 VDC 5 A(F)
48 VDC 36 VDC 59 VDC 3.15 A(T)
HI (125/250 VDC)
d
88 VDC 300 VDC 3.15 A(T)
HI (110/230 VAC)
d
85 VAC 265 VAC 3.15 A(T)
15 W
a
(F) denotes fast-acting fuse
b
(T) denotes time-delay fuse.
c
Power consumption varies based on configuration. 10/100Base-TX ports consume roughly 1 W less than
fiber optic ports.
d
This is the same power supply for both AC and DC.
5.2 Failsafe Relay Specifications
Voltage Current
30 VAC 0.3 A
30 VDC 1 A
80 VDC 0.3 A
5.3 Copper Ethernet Port Specifications
The following details the specifications for copper Ethernet ports that can be ordered
with the RUGGEDCOM RS8000T.
Speed
a
10/100Base-TX
Connector RJ45
Duplex
a
FDX/HDX
Cable Type
b
> CAT-5
Wiring Standard
c
TIA/EIA T568A/B
Maximum Distance
d
100 m (328 ft)
