File type Description Save Down‐
load
EDS Electronic Data Sheet (EDS)
Electronic data sheets for describing devices in the
EtherNet/IP mode
X --
Firmware Loading firmware updates X X
GSDML Information on the device properties (PROFINET) X --
HTTPS Cert HTTPS certificate
Maximum file size: 8192 bits
X X
LogFile File with entries from the event log table X --
MIB Private MSPS MIB file "Scalance_w_msps.mib" X --
RunningCLI This file contains an overview of the current configura‐
tion in the form of CLI commands. You can download
the text file. The file is not intended to be uploaded
again unchanged.
X --
Script CLI script file -- X
StartupInfo Startup log file X --
Users File with user names and passwords X X
WBMFav File with favorites X X
WLANAuthlog File with entries from the WLAN Authentication Log (in‐
formation on successful or failed authentication at‐
tempts)
X --
WLANCert
(in client mode only)
User certificate. You can specify a password for the
user certificate on the WBM page "Load&Save > Pass‐
word".
Maximum file size: 8192 bits
X X
WLANServerCert
(in client mode only)
Server certificate
Maximum file size: 8192 bits
X X
WLANSigRec
(in client mode only)
The zip file contains the following:
● csv file with the measured values of the signal
recorder
● pdf file with the measured values and an additional
graphic representation of the measured values.
You will find information about the measured values
and their graphic representation in the section "Signal
recorder".
X --
WLANSpectrumA‐
nalyzer
(Only in access
point mode)
The Zip file contains a csv file with the measured values
of the spectrum analyzer.
You will find information about the measured values
and their graphic representation in the section "Spec‐
trum analyzer".
X --
See also
Signal recorder (Page 116)
Spectrum analyzer (Page 155)
Configuration
4.2 Load and Save
SCALANCE W770/W730 acc. to IEEE 802.11n Command Line Interface
84 Configuration Manual, 09/2017, C79000-G8976-C324-08
