PROFINET IO functionality
6.4 Data record 0x802A (PDPortDataReal)
SCALANCE X-300 / X-400
Configuration Manual, 10/2014, C79000-G8976-C187-22
349
Value (hexadecimal)
Meaning
0x001E
1000BASETFD
0x001F
10GigBASEFX
0x0020 – 0x002D
Reserved
0x002E 100BASELX10
0x002F – 0x0035
Reserved
0x0036
100BASEPXFD
0x0037 – 0xFFFF
Reserved
DomainBoundary
Specifies which multicast addresses are blocked.
MulticastBoundary
The individual bits of the DWord variables specify which of the 32 first RT_CLASS_2
multicast addresses (from 01-0E-CF-00-02-00 bis 01-0E-CF-00-02-1F) is blocked.
Bit
Value
Meaning
0
1
The multicast MAC address 01-0E-CF-00-02-00 will be blocked.
0 The multicast MAC address 01-0E-CF-00-02-00 will not be
blocked.
...
1
The multicast MAC address 01-0E-CF-00-02-xx will be blocked.
0 The multicast MAC address 01-0E-CF-00-02-xx will not be
blocked.
31
1
The multicast MAC address 01-0E-CF-00-02-1F will be blocked.
0 The multicast MAC address 01-0E-CF-00-02-1F will not be
blocked.
LinkState
LinkState.Link
Value (hexadecimal)
Meaning
0x00
Reserved
0x01
Up (ready to send packets)
0x02
Down
0x03
Testing (no user data is transported)
0x04
Unknown (status cannot be identified)
0x05 Dormant (waits for external action)
0x06
Not present
0x07
LowerLayerDown
0x08 - 0xFF
Reserved
