Siemens SCALANCE X101-1 User Manual

SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02
15
Description of the device
3
3.1
Overview of the SCALANCE X-100 media converters
Table 3- 1 Overview of the product characteristics
Properties
X101-1
X101-1LD
SIMATIC environment + +
Diagnostics LED
+
+
24 VDC
+
+
2 x 24 VDC
+
+
Compact housing 40 mm (securing collar, etc.)
+
+
Signaling contact + on-site operation
+
+
Diagnostics: Web, SNMP, PROFINET
-
-
C-PLUG
-
-
Ring redundancy with RM
-
-
Passive ring redundancy
+
+
Standby redundancy
-
-
IRT capability
-
-
Fast learning
-
-
Passive listening
-
-
Log table
-
-
SNTP + SICLOCK
-
-
Cut Through
+
+
Table 3- 2 Overview of the connection options
X101-1
X101-1LD
TP (RJ-45)
Fast Ethernet 10 / 100 Mbps
1 1
Fiber multimode (BFOC)
1300 nm
1 -
Fiber long distance single mode (BFOC)
1310 nm
- 1

Siemens SCALANCE X101-1 Specifications

General

Brand	Siemens
Model	SCALANCE X101-1
Category	Media Converter
Language	English
