SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02
41
Technical specifications
7
7.1
SCALANCE X101-1
Table 7- 1 Technical specifications of the SCALANCE X101-1
Technical specifications
Order number
SCALANCE X101-1 6GK5101-1BB00-2AA3
Attachment to Industrial Ethernet
Quantity 1
Design
RJ-45 jack with MDI-X pinning
Properties
Full duplex
Transmission speed
100 Mbps
Optical connectors
Quantity
1
Design
BFOC socket
Properties
Full duplex to 100 Base-FX
Transmission speed
100 Mbps
Permitted cable lengths (Industrial
Ethernet)
Alternative combinations per length range
0 ... 85 m
• Max. 85 m IE FC TP Marine/Trailing Cable with IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Marine/Trailing Cable + 10 m TP Cord via
IE FC RJ45 Outlet
0 to 100 m
• Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180
• Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet
Optical parameters
Cable type
Multimode glass FO cable, cable cross sections 62.5/125 μm and 50/125 μm
Permitted cable length (glass FO
cable)
Cable cross-section
Permitted cable length
• 62.5/125 μm
• 50/125 μm
• 0 to 4000 m
• 0 to 5000 m
Attenuation ≤ 1 dB/km at 1300 nm
1200 MHz x km at 1300 nm
6 dB max. permitted FO cable attenuation with
3 dB link power margin
Bending radius
once without tensile force
100 mm
several times with tensile force
150 mm
Electrical data
Power supply Voltage range 18 to 32 VDC Safe Extra Low Voltage
(SELV)
