SCALANCE X-100 media converter
Operating Instructions, 04/2016, C79000-G8976-C346-02
27
The devices can be installed in the following ways:
● Installation on a 35 mm DIN rail
● Installation on a SIMATIC S7-300 standard rail
● Wall mounting
Keep to the minimum clearances so that the convection ventilation of the device is not
blocked.
● Below at least 10 cm
● Above at least 10 cm
Ambient temperature above 55 °C
If a device is operated in an ambient temperature of more than 55 °C, the temperature of
the device housing may be higher than 70 °C. The device must therefore be installed so
that it is only accessible to service personnel or users that are aware of the reason for
restricted access and the required safety measures at an ambient temperature higher than
55 °C.
If the cable or conduit entry point exceeds 70 °C or the branching point of conductors
exceeds 80 °C, special precautions must be taken. If the equipment is operated in an air
ambient in excess of 50 °C to 60 °C, only use cables with admitted maximum operating
temperature of at least 80 ℃.
