Technical specifications
7.1 SCALANCE X101-1
SCALANCE X-100 media converter
42 Operating Instructions, 04/2016, C79000-G8976-C346-02
Technical specifications
Rated voltage
24 VDC
Design
4-terminal plug-in block
Signaling contact
Design
2-terminal plug-in block
Current consumption
Typical
120 mA
Minimum rated current of the power
supply unit
170 mA
Power loss at 24 VDC
Typical
3 W
Overvoltage protection at input
PTC resettable fuse (0.5 A / 60 V)
Permitted ambient conditions
Ambient temperature
During operation
-10 ℃ to +60 ℃
During storage
-40 ℃ to +80 ℃
During transportation
-40 ℃ to +80 ℃
Relative humidity
During operation
≤ 95 % no condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. 56 ℃
ambient temperature
≤ 3,000 m above sea level at max. 50 ℃
ambient temperature
Design, dimensions and weight
Immunity
EN 61000-6-2
Emission
EN 61000-6-3
Degree of protection
IP30
MTBF (EN/IEC 61709, 40 °C)
152 years
Housing material Basic housing Die cast aluminum, powder coated
Front cover Polyphenylene ether + polystyrene
(PPE+PS plastic)
Weight 550 g
Dimensions (W x H x D)
40 x 125 x 124 mm
Installation options
• Mounting on a DIN rail
• Mounting on an S7-300 standard rail
• Wall mounting
Switching properties
Response to LLDP frames
Blocking
Response to spanning tree BPDU
frames
Forwarding
