Siemens SCALANCE X101-1 User Manual

Technical specifications
7.2 SCALANCE X101-1LD
SCALANCE X-100 media converter
44 Operating Instructions, 04/2016, C79000-G8976-C346-02
Technical specifications
Optical parameters
Cable type
Single mode glass FO cable
Cable cross-section
10/125 μm
Permitted cable length
0 to 26,000 m
Attenuation ≤ 0.5 dB/km at 1310 nm
13 dB max. permitted FO cable attenuation with 2 dB link power margin
Bending radius
once without tensile force
100 mm
several times with tensile force
150 mm
Electrical data
Power supply Voltage range 18 to 32 VDC Safe Extra Low Voltage
(SELV)
Rated voltage
24 VDC
Design
4-terminal plug-in block
Signaling contact
Design
2-terminal plug-in block
Current consumption
Typical
120 mA
Minimum rated current of the power
supply unit
200 mA
Power loss at 24 VDC
Typical
3 W
Overvoltage protection at input
PTC resettable fuse (0.5 A / 60 V)
Permitted ambient conditions
Ambient temperature
During operation
-10 ℃ to +60 ℃
During storage
-40 ℃ to +80 ℃
During transportation
-40 ℃ to +80 ℃
Relative humidity
During operation
≤ 95 % no condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. 56 ℃
ambient temperature
≤ 3,000 m above sea level at max. 50 ℃
ambient temperature
Design, dimensions and weight
Immunity
EN 61000-6-2 Class A
Emission
EN 61000-6-3
Degree of protection
IP30
MTBF (EN/IEC 61709, 40 °C)
134 years
Housing material
Basic housing
Die cast aluminum, powder coated
Front cover Polyphenylene ether + polystyrene
(PPE+PS plastic)
Weight
550 g
Dimensions (W x H x D)
40 x 125 x 124 mm
Installation options
• Mounting on a DIN rail
• Mounting on an S7-300 standard rail
• Wall mounting
