Siemens Sentron 3VA - Operator Kit with Bowden Cable (Max-Flex Operator); Elements of the Operator Kit with Bowden Cable

Accessories
4.5 Manual operators
3VA molded case circuit breakers with UL and IEC certification
286 Manual, 01/2019, L1V30435333-01
4.5.6
Operator kit with Bowden cable (Max-Flex operator)
4.5.6.1
Elements of the operator kit with Bowden cable
The Max-Flex operator is installed for switching a 3VA UL molded case circuit breaker using
a handle and Bowden cable through the panel door. The switching mechanism and handle
are connected to one another with a flexible Bowden cable.
①
Handle
②
Bowden cable
③
Switching mechanism
A variety of Bowden cable lengths are available.
