Siemens SENTRON 7KT1682

7KT multimeter
Manual, 08/2018, 2514284149-01
13
Description
3
3.1
Performance features
The 7KT1681 and 7KT1682 multimeters are designed such that they combine maximum
operating comfort with a wide range of advanced functions, and this despite the extremely
restricted dimensions of the modular enclosure (only 4U).
The backlit LCD offers intuitive operation of the clearly laid out user interface.
The 7KT1682 additionally features an insulated RS 485 communications interface with
Modbus protocol support.
Multimeter
Description
7KT1681
Universal meter without S0
interface
7KT1682
Universal meter with Modbus
RTU
Measurement
The 7KT1681 and 7KT1682 multimeters measure all the relevant electrical variables in an
AC system.
Interfaces
Optional interfaces depending on device version:
● RS 485 interface
● Digital input
● Digital output
Memory
Adjusted device parameters are permanently stored in the device memory.
