Description
3.4 Parameterization
7KT multimeter
Manual, 08/2018, 2514284149-01
25
Note
The devices allow you to create a backup copy of the data which can be edited using the
keys in EEPROM. You can write this data back
into RAM if required.
You can find more information on backing up and restoring this data in chapter
Command
(Page 36).
There are 3 special pages for energy meters:
● Active energy
● Reactive energy
● Apparent energy
Each page shows the total value and the partial value. You can find information about
resetting in chapter Command menu (Page 36).
Continuous display of measurement
If the unit is displayed continuously, this means that the measuring device is set for imported
(positive) energy.
To activate the display for exported (negative) energies, set parameter P02.09 to ON.
These energies are highlighted by flashing of the unit and by a negative sign.
