Description
3.3 7KT PAC1600 multimeter
7KT multimeter
Manual, 08/2018, 2514284149-01
17
1. Press the Menu key.
The main menu is displayed with the available options:
–
: Access the setup menu
–
: Access the command menu
–
: Password entry
The selected option flashes.
The text for the selection scrolls in the alphanumeric display.
If the password needs to be set, the menu opens with the
option already selected.
1. Press or to select an option.
2. Confirm with .
3. Press the Menu key to return to the measurement display.
Selection of measured values
Use the keys
and to scroll through the measurement display pages. The current page
is indicated by the unit in the upper left section of the display.
Some measurements may not be displayed on the device depending on programming and
the connection. If you have programmed for a system without a neutral conductor, for
example, the measurements for the neutral conductor will not be displayed.
