Siemens SENTRON 7KT1682

Description
3.4 Parameterization
7KT multimeter
30 Manual, 08/2018, 2514284149-01
M02 Utility
Unit
Default
Range
P02.01 Language – English
• English
• Italiano
• Francais
• Espanol
• Portuguese
• Deutsch
P02.02
High backlight level
%
100
0 … 100
P02.03
Low backlight level
30
0 … 50
P02.04 Low backlight delay s 5 … 600
P02.05 Default page return 60
• OFF
• 10 … 600
P02.06 Default page – VL-L
• VL-L
• VL-N
• …
P02.07 Default subpage INST
• INST
• HI
• LO
• AVG
• MD
P02.08 Display update time s 0.5 0.1 … 5.0
P02.09
Exported energy measure
– OFF
• OFF
• ON
P02.10
Phase energy measure
P02.11
U/I asymmetry measure
P02.12 THD harmonic measure
• OFF
• THD
• THD/HAR
P02.13 Power unbalance measure-
ment
• OFF
• ON
P02.14 Backlight flash when in
alarm
P02.05
•
OFF: Display always shows the most recently selected menu page.
•
Value set: The display returns to the page set using P02.06 after this time
has elapsed.
P02.06
Number of the page that is automatically displayed as soon as time P02.05
has elapsed since a key was pressed.
P02.07
Type of page to which the display returns after P02.05 has elapsed.
P02.09
Permits the measurement and display of exported energies.
