Siemens SENTRON 7KT1682

Commissioning
6.4 Modbus address register for devices with Modbus interface
7KT multimeter
54 Manual, 08/2018, 2514284149-01
Address
Number of
registers
Measured variable
Unit
Format
0C00H
2
2nd harmonic, L1 voltage
% Unsigned long
0C02H 2 3rd harmonic, L1 voltage
…
0C1AH
2
15th harmonic, L1 voltage
0C40H
2
2nd harmonic, L2 voltage
…
0C5AH
2
15th harmonic, L2 voltage
0C80H
2
2nd harmonic, L3 voltage
…
0C9AH
2
15th harmonic, L3 voltage
0CC0H
2
2nd harmonic, L1 current
…
0CDAH
2
15th harmonic, L1 current
0D00H
2
2nd harmonic, L2 current
…
0D1AH
2
15th harmonic, L2 current
0D40H
2
2nd harmonic, L3 current
…
0D5AH
2
15th harmonic, L3 current
0D80H
2
2nd harmonic, L1-L2 voltage
…
0D9AH
2
15th harmonic, L1-L2 voltage
0DC0H 2 2nd harmonic, L2-L3 voltage
…
0DDAH 2 15th harmonic, L2-L3 voltage
0E00H
2
2nd harmonic, L3-L1 voltage
…
0E1AH
2
15th harmonic, L3-L1 voltage
20F0H 1 Phase sequence
• 1 = o.k.
• 0 = not o.k.
– Unsigned int
