04/99 Displaying and Entering Values in Screens
Getting Started with C7-621-AS-i 41
Once the transfer is complete, the C7 starts up. When you press the
ENTER
key, the start screen is
displayed.
F1
F2
F3
F4
F5
SF
DC5V
FRCE
RUN
STOP
123
789
6
45
0
SIMATIC C7-621
ENTER
ESC
SHIFT
+/-
System_1
Pak
Activate the softkey
F5
to reach the system screen.
Enter a value in the input field.
F1 F2 F3
F4
F5
SF
DC5V
FRCE
RUN
STOP
123
7896
45
0
SIMATIC C7-621
ENTER
ESC
SHIFT
+/-
Max.number: 8
Back >>
Activate the softkey
F5
to reach the second screen entry. Now check the functionality of
your inductive proximity switch including the count function.
To Next Page
