Siemens SIMATIC ET 200SP Product Information

Supplements to ET 200SP documentation
2.5 I/O module manuals
Product information on the documentation of the ET 200SP distributed I/O system
50 Product Information, 02/2021, A5E03799595-BG
Section 3.1 Pin assignment; Supply voltage fuse protection
The module has neither short-circuit protection nor overload protection. Protect the module
from being destroyed by impermissible high current and install a fine fuse in the supply line.
The maximum rated current of the fine fuse depends on the hardware function status (FS) of
the module.
HW functional status of the
module
Max. rated current of fuse Tripping characteristic
FS ≤ 3
8 A
Quick response
FS ≥ 4
10 A
Quick response
Section 6.1 Technical specifications, Switching frequency with inductive load
The switching frequency of the outputs with inductive loads is max. 0.5 Hz.
Higher switching frequency is possible in spite of this, and depends on the alternating voltage
and switched inductors or the power factor of the electric motor used.
Alternating voltage Condition
Max. switching fre-
quency
200 VAC or lower
---
10 Hz
200 VAC or higher
• Power factor of the electric motor cos φ > 0.35
• Electric motor must only be turned off after
startup (no jogging mode).
Electric motors which are turned off during
startup could create inductive shutoff voltages
> 600 V, which could destroy the output elec-
tronics (Triac).
10 Hz
Section 6.1 Technical specifications
Supply voltage
Rated value (AC)
24 V to 230 V

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
