Installation and Startup
2-23
FM 456-2 Application Function Module Installation, Hardware, and Startup
C79000-G7076-C458-01
Connecting a Mouse
Connect the mouse to the IF 962-COM interface module.
A PS2 mouse must not be connected separately. If a PG keyboard is connected,
the trackball occupies the PS2-mouse interface.
Maximum Cable Lengths
Given in the table are the maximum cable lengths for connecting the individual
devices. A precondition is a hardware configuration with interference immunity.
Table 2-2 Maximum Cable Lengths for Operator Panels and Peripherals
Device
Maximum Length
Keyboard via
IF 962-VGA
2.5 m (8 ft. 3 in.)
Monitor (connection via VGA cable) via
IF 962-VGA
25 m (82 ft.)
Printer via
IF 962-LPT (parallel interface)
3 m (10 ft.)
RS232 interface e.g. terminal, printer
IF 962-COM
10 m (33 ft.)
2.11 Connecting a Programming Device or PC to the COM Interface
If you operate your FM 456-2 without monitor, keyboard and mass storage, you
need a PG or a PC to install the software. You can find out how to install this
software from the
M7-SYS manual
.
Connecting an FM 456-2 to the PG or to a PC via the COM interface
Connect the 9-pin subminiature D connector of the COM port on your IF 962-COM
interface module to the connector of a free COM port on your PG/PC. The
following methods of connection may be used:
Connection using control cables
Connection without control cables
