Technical specifications
8.4 Specifications
Basic Panels
136 Operating Instructions, 04/2012, A5E02421799-03
Supply voltage
KTP1000 Basic color DP KTP1000 Basic color PN TP1500 Basic color PN
Rated voltage
Range, permissible
+24 V DC
19.2 to 28.8 V (–20%, +20%)
Transients, maximum permissible 35 V (500 ms)
Time between two transients,
minimum
50 s
Current consumption
Typical
Constant current, maximum
Inrush current I
2
t
Approx. 600 mA
Approx. 1000 mA
Approx. 0.2 A
2
s
Approx. 800 mA
Approx. 1000 mA
Approx. 0.2 A
2
s
Fuse, internal Electronic
Miscellaneous
KTP1000 Basic color DP KTP1000 Basic color PN TP1500 Basic color PN
Software clock, synchronizable Yes
