Siemens SIMATIC HMI KTP600 Basic mono PN User Manual

Technical specifications
8.6 Functional scope with WinCC flexible and WinCC
Basic Panels
144 Operating Instructions, 04/2012, A5E02421799-03
Recipes
The specified values are maximum values and should not be used additive.
Object Specification Basic Panels
Quantity 5
Elements per recipe 20
Recipes
Data records per recipe 20
Safety
Object Specification Basic Panels
Number of user groups 50
Number of users 50
Safety
Number of authorizations 32
Infotexts
Object Specification Basic Panels
Length (no. of characters) 320
For alarms Yes
For screens Yes
Infotexts
For screen objects (for example, for I/O field, switch, button,
invisible button)
Yes
Additional functions
Object Specification Basic Panels mono Basic Panels color
Screen settings Touch screen calibration
Brightness setting
Contrast setting
Yes
1
-
Yes
Yes
1
Yes
2
-
Language change Number of languages 5
Graphic objects Vector and pixel graphics Yes
Trend views Quantity max. 25
Trends per view Quantity max. 4
Text objects Quantity 500
1
Not KP300 Basic mono PN and KP400 Basic color PN
2
Not KTP600 Basic mono PN, KTP600 Basic color PN, KTP600 Basic color DP

Siemens SIMATIC HMI KTP600 Basic mono PN Specifications

General

Resolution	320 x 240 pixels
Touchscreen	Yes
Interface	PROFINET
Power Supply	24 V DC
Mounting	Panel Mount
Operating Temperature	0 to 50 °C
Storage Temperature	-20 to 60 °C
Display Size	6 inches
Protection Rating	IP65 (front)
Display Type	Monochrome LCD
