Configure firmware
2.6 "Power" tab
Firmware/BIOS description SIMATIC IPC BX-39A, IPC PX-39A, IPC PX-39A PRO
Operating Instructions, 01/2023, A5E51110693-AA
31
2.6 "Power" tab
2.6.1 Level: "Power" tab
Device behavior after a power failure and after a "wake event".
Calling "Power" tab
Select: "Setup Utility (Page 10)" > "Power".
Firmware setting Value Setting in deliv-
ery state
Meaning
IPC BX-39A
IPC PX-39A
IPC PX-39A PRO
Wake on PME
Disabled
The device is not woken up when a Power Management
Event occurs.
Enabled
x
The device is woken up when a Power Management Event
occurs.
Wake on LAN 1
(X1 P1)
Disabled
The LAN controller of the onboard Ethernet interface "X1 P1"
cannot wake the device.
Enabled
x
The LAN controller of the onboard Ethernet interface "X1 P1"
can wake the device.
Wake on LAN 2
(X2 P1)
Disabled
The LAN controller of the onboard Ethernet interface "X2 P1"
cannot wake the device.
Enabled
x
The LAN controller of the onboard Ethernet interface "X2 P1"
can wake the device.
Requirement: The firmware setting "Wake on PME" must be
set to "Enabled".
USB Ports Wake up
during S5
Disabled
The USB ports with enabled wake function can only wake up
the system during sleep mode (S4). The system cannot be
woken up after shutdown (S5).
Enabled
x
The USB ports with enabled wake function can wake up the
system during sleep mode (S4) and after shutdown (S5).
USB Port 1 (X60)
Note: The USB port 1
(X60) is always sup-
plied with power
during operation.
Enabled
x
The affected USB port is only supplied with power during
operation. It is not supplied with power in sleep mode.
Enabled with
Wake Capability
The affected USB port is supplied with power both during
operation and in sleep mode.
Depending on the setting for the "USB Ports Wake up during
S5" switch valid for all USB ports, the affected USB port can
either only wake up the device in sleep mode (S4) or can
wake it up both in sleep mode (S4) and after shutdown (S5).
