Siemens SIMATIC IPC BX-39A Manual

Configure firmware
2.7 "Boot" tab
Firmware/BIOS description SIMATIC IPC BX-39A, IPC PX-39A, IPC PX-39A PRO
Operating Instructions, 01/2023, A5E51110693-AA
33
2.7 "Boot" tab
2.7.1 Level: "Boot" tab
Boot behavior of the device, bootable device components (boot media) and boot order.
Calling "Boot" tab
Select: "Setup Utility (Page 10)" > "Boot".
Firmware setting Value Setting in deliv-
ery state
Meaning
IPC BX-39A
IPC PX-39A
IPC PX-39A PRO
Quick Boot
Disabled
Quick start of the device is disabled.
Enabled
x
Quick start of the device is enabled.
During the boot procedure, various hardware function
tests are skipped. This shortens the boot procedure.
Quiet Boot
Disabled
During the self-test, start information appears in text
mode.
Enabled
x
The boot logo is displayed during the self-test.
Network Stack
Disabled
x
The UEFI Network Stack for network access under UEFI is
not available. For example, UEFI installation via PXE (Pre-
boot Executable Environment) is not possible.
Enabled
The UEFI Network Stack for network access under UEFI is
available.
• PXE Boot capabil-
ity
(only if "Network
Stack" = Enabled)
Disabled
x
Booting over PXE and booting
over HTTP are both disabled.
Only UEFI Network Stack is
supported.
PXE = Preboot Executable
Environment
PXE controls booting of a
boot image loadable over
the network.
HTTP = Hypertext Transfer
Protocol
HTTP control booting of a
boot image loadable via a
URL.
PXE:IPv4
Only network destinations
that support Internet protocol
version 4 are considered.
HTTP:IPv4
HTTP+PXE:IPv4
PXE:IPv6
Only network destinations
that support Internet protocol
version 6 are considered.
HTTP:IPv6
HTTP+PXE:IPv6
PXE:IPv4/IPv6
Network destinations that
support either Internet proto-
col version 4 or Internet pro-
tocol version 6 are
considered.
HTTP:IPv4/IPv6
HTTP+PXE:IPv4/IP
v6
