BIOS Setup (SCU)
3.6 Power menu
BIOS Description
32 Operating Manual, 05/2016, A5E33664825-AB
The following Setup parameter is visible if "Auto Wake on S5" is set to "By Every Day" or to "By Day
• Wake on S5 Time
Format
"Hour/Minute/
Second"
Sets the time of day when the device switches
on in the operating state S5.
You can use the <Enter> key to move within a
format, for example, from hour to minute. You
can use the <+> and <–> keys to set the
desired values for the time.
The following Setup parameter is visible if "Auto Wake on S5" is set to "" or to "By Day of Month".
Sets the day of the month when the device
switches on in the operating state S5.
Wake on LAN 1 (X1 P1)
3
The LAN controller of the onboard Ethernet interface can
switch the device on (Enabled) or not switch the device on
PROFINET always On
4
PROFINET port is On
The onboard PROFINET interface of CP1616 is supplied with
power in the operating states S4 and S5 (Enabled) or it is not
supplied with power (Disabled).
The following Setup parameter is visible if "PROFINET always On" is enabled.
• PROFINET Wake Capability
4
PROFINET can switch the device on in the operating state S4
or S5 (Enabled) or it cannot switch it on (Disabled).
USB Ports 0/1 (X61/X60) powered
3
USB Ports 4/5 (X63/X62) powered
3
USB Ports 3/6/8/9 powered
When activated (Enabled), the respective USB port is
supplied with voltage during operation.
When "Wake Capability" is also selected (Enabled), the USB
port is supplied with voltage in sleep mode as well.
The following Setup parameter is visible if "USB Ports # powered" is enabled.
• USB Port(s) # Wake Capability
The USB port can switch the device on (Enabled) or it cannot
switch it on (Disabled).
Only if the corresponding parameter "USB Ports # powered"
Only with Field programming device
Only with IPC6x7 and IPC8x7
Only visible with ordered device configuration with PROFINET
