1 Introduction
Reading QR Codes with SIMATIC MV320 via ET200SP CM PtP
Article ID: 109474684, V2.0, 10/2021
6
© Siemens AG
2021 All rights reserved
1.3 Components used
This application example was created with the following hardware and software
components:
Table 1-1
Component
Quantity
Item number
Note
Power supply
1
-
-
CPU315-2 PN/DP
1
6ES7315-2EH14-0AB0
Other PROFINET-
enabled CPUs from the
SIMATIC S7-300/
S7-400
range can also be used
ET 200SP
IM155-6PN ST
1
6ES7155-6AU00-0BN0
CM PtP
1
6ES7137-6AA00-0BA0
Base Unit
1
6ES7193-6BP00-0xA0
Server module
1
6ES7193-6PA00-0AA0
SIMATIC MV320 handheld
reader
1
6GF3320-0HT01
-
RS232 cable
1
6GF3 020-0AC40-0AC4
(EU)
6GF3 020-0AC40-0AC3
(USA)
-
STEP 7 V17 Professional
1
6ES7822-1AA07-0YA5
-
Note
If you use other hardware than in the example project, you must make the
corresponding changes in the hardware configuration.
Note
This description also applies to the STEP 7 V16 project.
This application example consists of the following components:
Table 1-2
Component
File name
Note
Project
"109474684_ET_200SP_CM_PtP_
MV320_PROJ_V17_V20.zip"
This compressed file contains the
V17 project.
Documentation
"109474684_ET_200SP_CM_PtP_
MV320_DOC_V20.pdf"
This description also applies to
the STEP 7 V16 project.
