Description of the device
1.2 CP 1616 communications processor
CP 1604 / CP 1616
22 Operating Instructions, 02/2017, C70000-G8976-C218-08
alternating fast flashing A disruption has occurred.
In this case, diagnostics via the Web or using SNMP is no longer
If this error occurs, please contact Technical Support. The problem
can be eliminated if you contact our specialists directly. You will find
the contact data in the section "Preface (Page 3)".
Resetting the firmware or restarting the PC will not eliminate the
Remember that apart from the LEDs visible on the front panel, there are also two "virtual"
LEDs in the firmware. These are the operating mode LEDs RUN and STOP. They do not
exist physically but can nevertheless be queried using SNMP. They are on in the RUN or
STOP mode and never flash normally or quickly.
The CP 1616 has a socket for connecting an external power supply.
With this power supply, the integrated real-time switch can operate even if the PC is turned
off.
The CP 1616 is intended for operation in Ethernet networks.
It also has the following features:
● The connectors are designed for 10BaseT and 100BaseTX.
● Data transmission speeds of 10 and 100 Mbps in full/half duplex are supported.
● Autonegotiation
● The module includes a 4-port real-time switch.
● Autocrossover
The connection of the CP 1616 to the LAN (
ocal
rea
etwork) is via one of the four RJ-45
jacks on the front panel of the CP.
The four jacks are connected to the integrated real-time switch.
