Operating hardware
4.2 Web server
CP 1604 / CP 1616
40 Operating Instructions, 02/2017, C70000-G8976-C218-08
Note
For the meaning of the LED signaling, refer to the section "
Description of the device
(Page
11)" of the relevant CP.
Virtual LEDs
Remember that apart from the LEDs visible on the front panel, there are also two "virtual"
LEDs in the firmware. These are the LEDs "RUN" and "STOP". They do not exist physically
but can nevertheless be queried using SNMP.
Object identifier (OID)
For the CP 1616
The private MIB variables of the CP 1616 have the following object identifier (OID):
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).siemensAD(4196)
.adProductMibs(1).simaticNet(1).iCP(9).iCP1616(1)
For the CP 1604
The private MIB variables of the CP 1604 have the following object identifier (OID):
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).siemensAD(4196)
.adProductMibs(1).simaticNet(1).iCP(9).iCP1604(2)
4.2
Web server
4.2.1
Web server
Introduction
Note
In the "Web server" section, the term CP 1616 is used for the CP 1616, the
CP 1616 onboard and the CP 1604.
The Web server provides you with the option of monitoring your CP 1616 via the Internet or
the internal company intranet. This allows evaluations and diagnostics over large distances.
Messages and status information are displayed on HTML pages.
