Operating hardware
4.1 Diagnostics with SNMP
CP 1604 / CP 1616
Operating Instructions, 02/2017, C70000-G8976-C218-08
37
OPC server (http://www.automation.siemens.com/mcms/industrial-
communication/de/ie/software/netzwerkmanagement/snmp-opc-server/seiten/snmp-opc-
server.aspx)
Note
The SIMATIC NET SNMP OPC server is not part of this product.
Profile files and MIB compilers
The range of information that can be monitored by the devices with the SIMATIC NET SNMP
OPC server depends on the particular device profile.
With the integrated MIB compiler of STEP 7/NCM PC, existing profiles can be modified and
new device profiles created for any SNMP-compliant device. It requires MIB files according
to the SMIv1 standard.
The SMIv1 MIB of the CP and a complete device profile are available on the supplied
product CD or can be downloaded from Support:
MIB (http://support.automation.siemens.com/WW/view/en/22414405
)
Variables of the MIB-II standard
Variables in the "System" directory
The following table shows several SNMP variables of the MIB II standard for monitoring the
device standard from the "System" directory:
sysDescr Read only Contains a vendor-specific identification of the device, for example "SIEMENS",
"SIMATIC NET", "CP 1616" or "CP 1604".
A string with up to 255 characters is used.
sysObjectID Read only Address (OID - Object Identifier) at which the device-specific SNMP variables
are accessible. On the CP 1616/CP 1604, the OID is:
1.3.6.1.4.1.4196.1.1.9.1 for CP 1616
1.3.6.1.4.1.4196.1.1.9.2 for CP 1604
sysUpTime Read only Time since the last reset, for example since power-up – This information is in
multiples of hundredths of seconds.
sysContact Read and write Here, you can enter the name of a contact person; factory default: empty string.
The possible value is string with a maximum of 255 characters.
sysName Read and write Name for the device; factory default: empty string
The possible value is string with a maximum of 255 characters.
