Operating hardware
4.1 Diagnostics with SNMP
CP 1604 / CP 1616
36 Operating Instructions, 02/2017, C70000-G8976-C218-08
Access with SNMP is controlled by the concept of communities.
Read and write access private
Meaning of the abbreviations/acronyms and sources of further information
In the following table, you can see the meaning of the abbreviations/acronyms used above
and can also see where you can obtain further information.
Simple Network Management Protocol
SNMP V2 Simple Network Management Protocol Version 2
(administration, protocol operations and security)
RFC 1901 and RFC 1905
SMIv1 Structure and Identification of Management Infor-
mation – Describes the structure of MIB objects.
RFC 1155
Management Information Base, Version 2
Private MIB MIB with product-specific expansions Section "Private MIB of a CP 1616/CP
SIMATIC NET SNMP OPC server
Description
The SIMATIC NET SNMP OPC server makes available the SNMP information from TCP/IP
networks on the OPC interface with SNMP. Using the SIMATIC NET SNMP OPC server, any
OPC client systems can access diagnostics and parameter data of SNMP-compliant
components, for example the product WinCC.
Non SNMP-compliant components can also be included in the plant visualization using their
IP addresses. Apart from simple device diagnostics, this also allows detailed information
such as the network load distributions of entire TCP/IP networks. With the additional
monitoring of this data, device failures can be detected and localized quickly. This increases
operational safety and improves plant availability. You configure the devices to be monitored
by the SIMATIC NET SNMP OPC server with STEP 7 (alternatively with NCM PC).
You will find further information on the SIMATIC NET SNMP OPC server on the Internet at
the URL:
