Hardware installation
2.2 CP 1616 communications processor
CP 1604 / CP 1616
Operating Instructions, 02/2017, C70000-G8976-C218-08
29
4. Remove the CP 1616 from its packaging.
Note
When handling the module, make sure that you do not touch the connectors or the
electronic components.
5. Insert the CP 1616 the PCI slot. Make sure that the CP 1616 sits firmly and uniformly in
the socket of the slot.
6. Close the computer housing as described in the manual accompanying your PG/PC.
7. Plug the connecting cable (TP) into the appropriate socket on the front panel of the CP
1616.
8. Plug the power supply connector into the socket again and turn on your computer.
Note
If you insert the CP 1616 in a
suitable PCI slot and then secure the metal plate to the
housing, the module sometimes skews in the slot in computers of some manufacturers.
After securing the module, please make sure that it is still sitting correctly and firmly in the
slot!
