Requirements for use
2.2 Configuration
CP 343-1 ERPC
12 Manual, 03/2010, C79000-G8976-C239-02
CPU Order number
CPU 315F-2 DP 6ES7 315-6FF01-0AB0
CPU 315F-2 PN/DP 6ES7 315-2FH10-0AB0
6ES7 315-2FH13-0AB0
CPU 315T-2 DP 6ES7 315-6TG10-0AB0
CPU 317-2 DP 6ES7 317-2AJ10-0AB0
CPU 317-2 PN/DP 6ES7 317-2EJ10-0AB0
6ES7 317-2EK13-0AB0
CPU 317F-2 DP 6ES7 317-6FF00-0AB0
6ES7 317-6FF03-0AB0
CPU 317F-2 PN/DP 6ES7 317-2FJ10-0AB0
6ES7 317-2FK13-0AB0
CPU 317T-2 DP 6ES7 317-6TJ10-0AB0
CPU 318-2 6ES7 318-2AJ00-0AB0
CPU 319-3 PN/DP 6ES7 318-3EL00-0AB0
2.2 Configuration
STEP 7 version required
The following version of STEP 7 is required:
STEP 7 version Functions of the CP
STEP 7 V5.4
+ Service Pack 5
+ Hotfix 5
+ Hardware Support Package HSP 1032
Required for configuration in STEP 7 (hardware catalog of
HW Config) and the ERPC functions
Installation of the Hardware Support Package HSP 1032
You will find the HSP on the Internet at the following address:
ID 23183356 (http://support.automation.siemens.
com/WW/view/en/23183356)
Install the HSP in STEP 7 / HW Config in the "Options" menu with the "Install Hardware
Updates" menu command. You will find further information in the STEP 7 online help (under
"HSP" or "Hardware update").
After installing the HSP, close STEP 7. After restarting STEP 7, the CP is in the catalog of
HW Config.
Downloading the STEP 7 configuration data
You can download the configuration data to the CP via the MPI interface of the CPU and the
backplane bus or directly over LAN/Industrial Ethernet. For more detailed information, refer
to section Downloading ERPC configuration data (Page 52).
