3.2 Device view
On the device front:
① Ethernet connectors (P1, P2, P3, P4, P5)
② SET button
③ Digital input (DI)
④ Digital output (DO)
⑤ Power supply connection
⑥ LED display
On the device rear:
⑦ PLUG slot
3.3 Scope of delivery
The following components ship with the product:
• A SCALANCE S device
• A 5-pin terminal block for the power supply
• A 2-pin terminal block for the digital output
• A 2-pin terminal block for the digital input
• A product DVD
Description of the device
3.3Scope of delivery
SCALANCE S615
20 Operating Instructions, 05/2023, C79000-G8976-C389-08
