Technical speci󹪝cations
8
 SCALANCE S615
Article number 6GK5 615-0AA00-2AA2
6GK5 615-0AA01-2AA2
Ethernet interface
Attachment to Industrial
Ethernet

Quantity 5
Design

RJ-45 jack
Characteristics:
• 10/100BASE-T
• Ethernet IEEE 802
• 10/100 Mbps
Electrical data
Power supply Input voltage 12 to 24 VDC
min. 10.8 VDC, max. 28.8 V
Maximum power con‐
sumption
3W
Digital input Quantity 1
Design Terminal block, 2 terminals
Characteristics: Rated voltage 24 VDC Safe Extra Low Voltage (SELV)
For state "1": 13 to 30 VDC
For state "0": -30 to 3 VDC
Maximum input current 8 mA
Cables should be routed in pairs
Maximum cable length < 30 m
Inputs isolated from electronics.
Digital output Quantity 1
Design Terminal block, 2 terminals
Properties Rated voltage 24 VDC Safe Extra Low Voltage (SELV)
internally not current limited
Maximum current carrying capacity 1 A
Cables should be routed in pairs
Maximum cable length < 30 m
Output isolated from electronics
Permitted ambient conditions
SCALANCE S615
Operating Instructions, 05/2023, C79000-G8976-C389-08 61
