5.2 Power supply
The power supply is connected using a 5-pin terminal block. The power supply is non-󹪞oating.
/
/
0
0
PIN Signal Description
1 L1+ 24 VDC
2 M1 Ground
3 M2 Ground
4 L2+ 24 VDC
5 Functional ground, refer to the section "Grounding (Page50)"
You can 󹪝nd information on wiring in the section "Terminals (Page23)".
External power supply
Refer to the section Connecting up (Page43) and the installation instructions and instructions
for use of the manufacturer of the power supply, the battery or the accumulator.
