Configuring with Web Based Management
4.3 "Information" menu
SCALANCE SC-600 Web Based Management (WBM)
116 Configuration Manual, 10/2021, C79000-G8976-C475-03
• Type of Connection (Server)
Shows which type of connection is set on the SINEMA RC Server.
• Type of Connection (Device)
Shows which type of connection is set on the device.
• Fingerprint
Shows the fingerprint of the server certificate. Is only displayed when the fingerprint
is used for verification.
• Remote Address
Shows the IP address of the SINEMA RC Server.
• Connected Local Subnet(s)
Shows the IP addresses of the local subnets. Is only displayed when the option
"Connected local subnets" is enabled on the SINEMA RC Server. You will find further
information on this in the Operating Instructions of the SINEMA RC Server.
• Connected Local Host (s)
Shows the destination IP address of the hosts that can be reached.
• Tunnel Interface Address
Shows the IP address of the virtual tunnel interface.
• Connected Remote Subnet(s)
Shows the subnets of the SINEMA RC Server that are reachable for the device. Which
subnets are reachable for the device depends on the communications relations on the
SINEMA RC Server. You will find further information on this in the Operating
Instructions of the SINEMA RC Server.
4.3.18 OpenVPN
4.3.18.1 Client
The WBM page shows the status of the activated OpenVPN connections.
