Configuring with Web Based Management
4.4 "System" menu
SCALANCE SC-600 Web Based Management (WBM)
164 Configuration Manual, 10/2021, C79000-G8976-C475-03
Note
The maximum is 128 entries.
The table has the following columns:
• Select
Select the check box in the row to be deleted.
• Pool ID
Shows the number of the address band.
• Identification Method
Shows the method with which the client identifies itself with the DHCP server.
• Value
Shows the MAC address or client ID or DUID of the client.
• IP Address
Specify the IPv4 address that will be assigned to the client. The IPv4 address must be
within the address band.
• Comment
Enter a description for the address assignment.
The maximum is 32 characters.
