Modules
4.4Installing/Removing Power Modules
3. Insert the new module into the slot.
2
1
3
1
Module
2
Chassis
3
Screw
Figure4.3 Installing a Module
4. Tighten the screws to secure the module.
5. [Optional] If necessary, install the device in the rack.
4.4 Installing/Removing Power Modules
The RUGGEDCOM RX1511 supports a single power module.
1
1
Power Module
Figure4.4 Power Module
42
RUGGEDCOM RX1511
Installation Manual, 04/2021, C79000-G8976-1056-20
