Introduction
1.3Required Tools and Materials
• Red = Alarm
Compact Flash Card Port Houses the CompactFlash (CF) card that contains active and backup
installations of RUGGEDCOM RUGGEDCOM RX1511, along with
the configuration database and other system data. For more
information, refer to "Accessing the CompactFlash Card (Page
21)".
1.3 Required Tools and Materials
The following tools and materials are required to install the RUGGEDCOM RX1511:
Tools/Materials Purpose
AC/DC power cord (16 AWG) For connecting power to the device.
Lightning protector For protecting the device from harmful electrical
strikes.
Shielded coaxial cables For connecting the device to antennas and an
Ethernet network.
SIM Card(s) provided by the network carrier For accessing a network carrier's cellular network.
Required only if a cellular modem module is
equipped.
Flathead screwdriver For mounting the device to a DIN rail.
Phillips screwdriver For mounting the device to a panel.
4 x #6-32 screws For mounting the device to a panel.
Braided or equivalent ground wire For grounding the device to safety Earth.
1.4 Decommissioning and Disposal
Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
Decommissioning
This device may include sensitive, proprietary data. Before taking the device out of
service, either permanently or for maintenance by a third-party, make sure it has
been fully decommissioned.
For more information, refer to the associated Configuration Manual.
Recycling and Disposal
For environmentally friendly recycling and disposal of this device and related
accessories, contact a facility certified to dispose of waste electrical and electronic
equipment. Recycling and disposal must be done in accordance with local
regulations.
RUGGEDCOM RX1511
Installation Manual, 04/2021, C79000-G8976-1056-20
3
